Daisy 14
SKU : Daisy 14
Ceiling Mount LED Lighting Daisy-14 Luminaire is Vapor Tight, Water and Dustproof. This fixture is built using high efficiency LED strips with a Dimmable and pro-grammable Phillips Driver, Daisy-14 features an IP67 rated enclosure. Comes with standard Stainless Steel Hardware, Silicone Seals and Polycarbonate Frosted Lens. Great for food processing facilities, Com-mercial Kitchens, Breweries, Industrial Facilities, Livestock Contain-ment Buildings, Parking Garages, Laundries, Car Washes, Underpasses, Tunnels.-10 Year / 100,000 hour Limited Warranty.
Features :
- Energy Savings: Over 66% compared to HID light sources
- Improved lumen maintenance
- Utilizes high efficient Phillips lumileds LED’s
- Operating temperatures: -30°C ~ 60°C
- Driver: Constant current, 120-277v, 50/60Hz, 480v (Optional)
- Suitable for wet locations
- 0-10v dimming 80CRI (standard) up to 5000 lumen output
- Operating Life: >60,000 hours
- White Polycarbonate Body with Stainless Steel Clips
- Frosted polycarbonate lens
- 1/2” rubber plugs for conduit, sensors or photo cell mounting.
- Silicone gasket to prevent leakage and provide weather-tight protection.
- Mounting: Surface mount
- UL Listed for Wet Locations
Wattage : Color Temp. :
- 3000K (30K)
- 4000K (40K)
- 5000K (50K)
Finish : White (WHT)
Mounting : Ceiling Mount (CM)
Options :
- Motion Sensor (OCC)
- Button Photocell (PC)
- Emergency Batt. Pack (EMR)
- Wireless Control (WC)
Dimensions :
Cat# : DAY14
- A : 50”
- B : 4” 1/8
- Input Power : 40W
- Lumen Output : 4,120
- LPW : 103
- Color Temp.(CCT) : 5000K
- CRI : 70+
- Rated Life (L70) : >200,000
- Imput Voltage : 120-277V
- Flourescent Equivalent : 2-23W T8
Cat# : DAY14-52CLED
- Input Power : 56W
- Lumen Output : 5,545
- LPW : 106
- Color Temp.(CCT) : 5000K
- CRI : 70+
- Rated Life (L70) : >200,000
- Imput Voltage : 120-277V
- Flourescent Equivalent : 3-32W t8
