Architectural LED Column Light – Astral (AST)
Astral is a modern architectural LED column lighting solution constructed with rugged aluminum alloy. It is ideal for exteriors, walkways, perimeters, school campuses, industrial and commercial spaces, and recreational parks.
- 10-year / 100,000-hour limited warranty
- Heavy-duty cast aluminum housing
- 3 mil powder coat finish
- Optics: Type II, III, IV & V clear optics
- Silicone gasket with IP66 protection
Available Models
| Model |
Wattage |
Lumen Output |
| AST-12CLED |
12W |
1,374 lm |
| AST-25CLED |
25W |
2,626 lm |
| AST-35CLED |
35W |
3,469 lm |
| AST-45CLED |
45W |
4,035 lm |
| AST-50CLED |
50W |
4,460 lm |
Technical Specifications
| Parameter |
Details |
| Input Voltage |
120–277V (Universal) |
| Frequency |
50/60 Hz |
| CRI |
70+ |
| Rated Life (L70) |
>200,000 hours |
| Distribution |
Symmetric (SMT) |
| Protection Rating |
IP66 |
Performance by Wattage
| Wattage |
Lumens |
CCT |
CRI |
Voltage |
Lifetime |
| 12W |
1,374 |
5000K |
70+ |
120–277V |
>200,000 hrs |
| 25W |
2,626 |
5000K |
70+ |
120–277V |
>200,000 hrs |
| 35W |
3,469 |
5000K |
70+ |
120–277V |
>200,000 hrs |
| 45W |
4,035 |
5000K |
70+ |
120–277V |
>200,000 hrs |
| 50W |
4,460 |
5000K |
70+ |
120–277V |
>200,000 hrs |
Diameter Options
| Code |
Size |
| 6 |
6" O.D |
| 8 |
8" O.D |
Color Temperature (CCT)
| Code |
Description |
| 3K |
3000K (Warm White) |
| 4K |
4000K (Neutral White) |
| 5K |
5000K (Cool White) |
Finish Colors
| Code |
Color |
| BZ |
Bronze |
| GRY |
Gray |
| BLK |
Black |
| WH |
White |
| CST |
Custom |
Optional Add-ons
| Code |
Option |
| PC |
Photocell |
| WC |
Wireless Control |
Base / Height Options
| Height (A) |
Base (B) |
| 36" |
12" |
| 42" |
12" |
| 6'-5" |
24" |
| 7'-5" |
35" |
| 8'-5" |
35" |
| 10'-5" |
35" |
| 12'-5" |
48" |
Shade Dimensions
| Height (A) |
Base (B) |
Top (C) |
| 36" |
12" |
19" |
| 42" |
12" |
25" |
| 6'-5" |
24" |
4' |
| 7'-5" |
35" |
4' |
| 8'-5" |
35" |
5' |
| 10'-5" |
35" |
7' |
| 12'-5" |
48" |
8' |
